Cone Crusher – High-Performance Crushing Solution for Mining and Construction
Table of Contents
Product Description
The cone crusher is a powerful and efficient crushing machine designed for medium and fine crushing of hard and medium-hard ores and rocks.
It is widely used in metal ore mining, non-metallic ore processing, and construction aggregate production. With a large crushing ratio,
high efficiency, low energy consumption, and uniform output size, this machine significantly improves production capacity and operational reliability.
The cone crusher features a robust structure, advanced spring protection system, and a wedge or shim adjustment system for easy discharge port adjustment.
It is built for heavy-duty performance in harsh mining and industrial conditions.
Product Features
- High crushing efficiency with low energy consumption
- Suitable for crushing various types of ores and rocks
- Adjustable discharge size with wedge or shim mechanism
- Durable structure and low maintenance requirements
- Spring overload protection to prevent damage from uncrushable materials
- Available in standard, medium, and short head types to meet different needs
Technical Parameters
| Model | Feed Opening Max Size (mm) | Recommended Max Feed Size (mm) | Discharge Port Size (mm) | Capacity (T/H) | Power (KW) | Speed (R/Min) | Voltage (V) | Oscillations (min) | Spring Pressure (T) | Weight (T) |
|---|---|---|---|---|---|---|---|---|---|---|
| 900 Std/Med/Short | 135 / 70 / 50 | 115 / 60 / 40 | 15-50 / 5-20 / 3-13 | 50-90 / 20-65 / 15-50 | 55 | 730 | 380 | 333 | 70 | 10.82 |
| 1200 Std/Med/Short | 170 / 115 / 60 | 145 / 100 / 50 | 20-50 / 8-25 / 3-15 | 110-168 / 42-135 / 18-105 | 110 | 730 | 220/380 | 300 | 150 | 25 |
| 1750 Std/Med/Short | 250 / 215 / 100 | 215 / 185 / 85 | 25-60 / 10-30 / 5-15 | 280-480 / 115-320 / 75-230 | 155 | 735 | 220/380 | 245 | 300 | 50 |
| 2200 Std/Short | 350 / 130 | 300 / 100 | 30-60 / 5-15 | 590-1000 / 120-340 | 280 | 500 | 6000 | 220 | 400 | 79 / 80 |
Application Scenarios
Metal Ore Mining
Cone crusher is ideal for crushing copper ore, iron ore, and gold ore into smaller particles suitable for further beneficiation processes.
It ensures uniform particle size and increases ore recovery rate.
Non-metallic Ore Processing
It efficiently handles materials like limestone, marble, and quartzite for use in cement, construction, and chemical industries.
Construction Aggregate Production
Produces high-quality aggregates for concrete, highway, bridge, and infrastructure projects with consistent shape and size.
After-Sales Service
- Quality assurance for 1 year except for vulnerable parts, human factors and natural disasters.
- Support engineers to provide on-site guidance for installation and commissioning;
- 7*24 hours online communication and guidance;
- Product manuals and installation videos are provided;
